3-in-1 On-Board Charger (3.3kW, Air-Cooled)
A cost-efficient, lightweight, air-cooled 3-in-1 charging solution for compact and low-speed EVs
Key Features
Highly Integrated
OBC, DC/DC, and power management in a lightweight 3-in-1 package
Ambient Cooling
Air-cooled design reduces system requirements
High Efficiency
Improved energy conversion directly contributes to range for compact EVs
Automotive-Grade Safety
Full electronic protection and CAN communication support
Specifications
OBC
DC/DC
Overall Unit
Parameter
Value
OBC
Input Voltage Range
90-264VAC
Output Voltage Range
250V—450VDC rated 380V
Maximum Output Current
12A
Rated Output Power
3.3kW
Peak Efficiency
≥96%
DC/DC
Input Voltage Range
250V—450VDC Rated 380V
Maximum Output Current
94A
Rated Power
1.1kW （80±1A）
Peak Power
1.3kW (94±1A 3min)
Efficiency
≥93% (100% load); ≥91% (50% load)
Overall Unit
Dimensions(L×W×H)
311x266x136mm
Weight
7.8kg
